Description

Triple Compartment Neuron Device (500 μm microgroove barrier)

Each box contains (5) Silicone Devices

Silicone Device

Cat.No: TCND500

Size: ~ 38 mm – ~24mm

The TCND500 consists of (2) 500 μm microgroove barriers with a 500 μm central compartment. This device makes it possible to culture cortical neurons in the left and right chambers while culturing hippocampal neurons, or other combinations of cells, in the middle. The triple compartment is also suitable for transport studies where the researcher wishes to treat the middle of the axon growing in the middle compartment while observing effects at the growth cone or in the somal compartment. Neurons can also be loaded in the central compartment and different treatments applied to the left and right compartments.

ChipTray™系列 特点 组织培养芯片和设备用外壳 减少蒸发，延长培养活力 与显微镜兼容 神经元长期培养过程中培养基的挥发对细胞的健康有很大的影响。这在微流控设备和芯片中尤其适用，因为它们孔更小。为了克服这些问题，Xona公司开发了一种专利芯片ChipTray™ 与XonaChips®硅树脂设备和所有其他微流控设备一起使用。除减少蒸发外，ChipTray™为使用空气物镜的相位对比成像提供了优化的外壳。 托盘的占地面积与标准ANSI微型板架兼容。托盘两端有两个水槽，XonaChips®有两个槽（XC150、XC450、XC900、XC-T-500或XC-T-1000）。安装在玻璃上的硅胶装置或任何其他想要使用的基于幻灯片的微流控装置也与这些托盘兼容。在每个槽内都有一个切口，用倒置显微镜提高图像质量。芯片盘已准备好组织培养。
